2mag Hotplate 15 magneetroerder met verwarming 15 x 1000 ml
Art.Nr.
L131966315

2mag Hotplate 15 magneetroerder met verwarming 15 x 1000 ml

Art.Nr.
L131966315

Temperatuurbereik tot 200°C
Maximaal 1000 ml per roerplaats
Aftand tussen roerplaatsten 65 mm
Snelheid van 100 tot 2000 rpm
Afmeting (bxdxh) 250 x 430 x 75 mm

Gewicht circa 15 kg
Inclusief externe besturingsunit heatMIXcontrol

Bekijk alle specificaties
Specificaties
Specificaties
Merk 2 mag
Max. volume per roerpositie (H2O) 1
Min. RPM 100
Max. RPM 2.000
Max. Temperatuur 200
Productbeschrijving

2mag Hotplate 15 magneetroerder met verwarming 15 x 1000 ml

Stirring-heating plate combination with 15 stirring positions, incl. control unit heatMIXcontrol, universally applicable for miscellaneous vessel sizes and shapes, stirring point distance 65 mm, suitable for 15 x 250 ml beaker glasses (tall form).

Stirring - Powerful 15 stirring points, maintenance-free and wear-free by inductive 2mag-Magnetic-Drive concept, extremely wide speed range of 100 to 2,000 rpm, 100% synchronized speed, jerk-free stirring even at low speeds, 10-step power settings of the stirrer, high power setting for viscous liquids and reduced power setting for long-term operation without any heating effects caused by the stirrer, clear digital display for settings of stirrer speed, stirrer power and temperature of the integrated heater, SoftStart procedure for reliable catching/centering and safe acceleration of the stirring bar.

Heating - Heating plate made of resistant aluminium alloy, PTFE-coated for increased chemical resistance and easier cleaning, fast heating-up by powerful integrated electrical heater, homogenous temperature distribution, maximum heating temperature +200 °C, PowerDetect for automatic compensation of physically determined loss in stirring power which can come up to 40% at high temperatures, independent over-temperature protection inside the plate.

Inclusive separate control unit for operation of magnetic stirrer and integrated heater, for long-term protection of the electronics against aggressive liquids and gases as well as thermal influences, stainless steel housing.

Type STIRRING HOTPLATE 15
Stirring positions 15
Stirring positions distance 65 mm
Stirring volume/stirring point 1 - 1,000 ml
Stirring power (max.) 40 W
Power setting 4 - 40 W (10-step)
Temperature (max.) +200 °C
Speed range 100 - 2,000 rpm
Electrical data 230 V / 1,200 W
Dimensions (WxDxH) 250 x 430 x 75 mm
Protection category IP20
Weight (gross) approx. 15 kg
